APM wire mesh loom speed

2023-12-06

The best economic speed is selected on the loom process, after using this speed, the equipment has a

long life, less material and tooling consumption, good product quality, saving labor and time, and achieving

the best economic benefits.

1.1 Some basic principles of selecting the speed of loom:

--- When the tensile strength of the metal wire material is smaller and the elongation is smaller, the lower

speed braiding should be selected.

--- Plain high mesh with high weaving difficulty and high beating up force, the lower speed should be

selected.

--- The wire materials with a large elastic modulus, the lower speed weaving should be selected .

--- Weaving width is more bigger, the lower speed weaving should be selected.

----The actual weaving speed should not exceed the design range.

The speed of the loom directly affects the production efficiency and the quality of the cloth. In practice,

it is very important to work out the best economic speed of all kinds of cloth on the same type loom.
